FiiO launch a transparent portable cassette player

FiiO launch a transparent portable cassette player

,

The eye-catching player goes on sale this week at CA$ 149.49 / US$ 129 / £99. 2024 benefits include USB-C charging, 13-hour battery life and an all analog circuit for a enhanced yet classic sound. Calling all bandcamp fans!

__________

Classic sound, enhanced

For truly analogue playback, the entirety of the CP13’s audio circuit uses analogue devices – from the magnetic tape head all the way to the signal amplification. The result is a classic, unmistakably analogue sound.

The CP13’s motor is powered by a high voltage 4.2V power supplymore than the 1.8V or 3V typically found in portable cassette players. This power supply works in tandem with a custom motor speed stabilization circuit, which increases the drag on the motor as necessary to ensure stable movement speeds – which mitigates unwanted pitch changes and also allows the CP13 to be able to handle more cassette tape types.

Unlike the single-ended signal acquisition typically found in current cassette players, the CP13 employs a differential circuit for balanced acquisition of signals from the custom head, ensuring more stable signal transmission, higher signal-to-noise ratio, and lower distortion.

Compact convenience

Though ultimately restricted by the size of the cassette player’s movement, FIIO engineers paid much attention to making the CP13 as compact as possible. Through the integration of manufacturing and structural design ingenuity, the CP13 ended up only being 31.8mm thick, making it thinner and more compact than most portable cassette players.

The CP13 is powered by a lithium battery, which can be charged through the USB Type-C port. The battery is lighter than original AA batteries in previous players and lasts for 13 hours per charge.

SPECIFICATION

  • Battery Capacity: 1800 mAh
  • Battery Life: 13 Hours
  • Op-Amp: JRC5532
  • Flywheel: Copper
  • Mechanical Core: Customised Mechanical Core
  • Head: Customised Balanced Amplification Magnetic Head
  • 3.5mm Power Output: 250mV
  • SNR: >55dB
  • Dimensions: 120mm x 88.3mm x 31.8mm
  • Weight: 310g

The FiiO CP13 is available now.
